The Offroader is the largest in the range and comes standard with brakes and heavy-duty coupler. The version with extra features is designed for serious outdoor adventurers. This trailer has much to offer, especially with the additional extra features.
Features
Offroader Braked With Extended Standard Features
see Extended Standard Features with this link
• Rear drawout rack for ammo boxes 900mm x 1130mm
• Side drawout rack for ammo boxes 455mm x 1075mm
• Washing table nylon storage rollers and two elastic bungee cords
• Lockable water tank filler cap
• Stainless steel washing table mounting brackets
• Zinc galvanised coupler ‘Sigma Autoreverse type’
• Two pad-lockable jerry can holders (We recommend a 20 litre metal Proquip jerrycan, not included)
• One heavy duty roof rack with table compartment able to carry a large tent
• Two pad-lockable enclosures (equipment or tool box)
• Two extending supporting back stays and one jockey wheel to provide levelling and stability when parked on uneven ground
• 15 inch 6 stud rims with 215 tyres for rough terrain
• One spare wheel
• Epoxy coated in white, beige or green, manufactured from quality zinc galvanised sheet steel
• 4 ring holders to tighten luggage
• Adjustable jockey wheel
• Axle capacity 1800kg
• 2 Gabriel shock absorbers
• 12 blade 36 inch leaf springs
• Lockable tailgate that serves as a table top
• Multi-function LED lights
• 1 x pad-lockable toolbox/electrical box with caravan plug
• Swing-out spare wheel attachment with maintenance free vesconite bushes
• Large new nosecone with 4 tie-down rings able to house an 80 litre fridge, accessible from the front, with spring assisted flap for access to fridge controls
| Dimensions | ||
| A | Height (over all) | 1570 mm |
|---|---|---|
| B | Height (side) | 800 mm |
| C | Length (body) | 2100 mm |
| D | Length (over all) | 3800 mm |
| E | Width (inside) | 1100 mm |
| F | Width (over all) | 1780 mm |
| G | Ground Clearance | 330 mm |
| I | Length (nose-cone) | 670 mm |
| Technical Info | |
| Tare Mass | 500 kg |
| GVM | 1530 kg |
| Pay Load | 1030 kg |
| Brakes | Run-in |
| Axle Length | 1530 mm |
| Axle Capacity | 1800 kg |
| Leaf Springs | 12 Blade 36 inch |
| Wheels | 215 x 15 inch |
| Doors | |
| Door (rear – height) | 560 mm |
| Door (rear – width) | 1020 mm |
| Door (side – height) | 540 mm |
| Door (side – width) | 650 mm |
