Venter Offroader Braked

The Offroader is the largest in the range and comes standard with brakes and heavy-duty coupler. The version with extra features is designed for serious outdoor adventurers. This trailer has much to offer, especially with the additional extra features.

Features

Offroader Braked With Extended Standard Features

Rear drawout rack for ammo boxes 900mm x 1130mm
Side drawout rack for ammo boxes 455mm x 1075mm
Washing table nylon storage rollers and two elastic bungee cords
Lockable water tank filler cap
Stainless steel washing table mounting brackets
Zinc galvanised coupler ‘Sigma Autoreverse type’
Two pad-lockable jerry can holders
One heavy duty roof rack with table compartment able to carry a large tent
Two pad-lockable enclosures (equipment or tool box)
Two extending supporting back stays and one jockey wheel to provide levelling and stability when parked on uneven ground
15 inch 6 stud rims with 215 tyres for rough terrain
One spare wheel
Epoxy coated in white, beige or green, manufactured from quality zinc galvanised sheet steel
4 ring holders to tighten luggage
Adjustable jockey wheel
Axle capacity 1800kg
2 Gabriel shock absorbers
12 blade 36 inch leaf springs
Lockable tailgate that serves as a table top
Multi-function LED lights
1 x pad-lockable toolbox/electrical box with caravan plug
Swing-out spare wheel attachment with maintenance free vesconite bushes
Large new nosecone with 4 tie-down rings able to house an 80 litre fridge, accessible from the front, with spring assisted flap for access to fridge controls

Optional Equipment

Tent with ladder for two to four adults (tent fitted if bought with trailer)
Gas stove kitchen unit with spice rack
Lid Netbag storage

Dimensions
A Height (over all) 1570 mm
B Height (side) 800 mm
C Length (body) 2100 mm
D Length (over all) 3800 mm
E Width (inside) 1100 mm
F Width (over all) 1780 mm
G Ground Clearance 330 mm
I Length (nose-cone) 670 mm
Technical Info
Tare Mass 500 kg
GVM 1530 kg
Pay Load 1030 kg
Brakes Run-in
Axle Length 1530 mm
Axle Capacity 1800 kg
Leaf Springs 12 Blade 36 inch
Wheels 215 x 15 inch
Doors
Door (rear – height) 560 mm
Door (rear – width) 1020 mm
Door (side – height) 540 mm
Door (side – width) 650 mm

Description

Venter Offroader Braked

The Offroader is the largest in the range and comes standard with brakes and heavy-duty coupler. The version with extra features is designed for serious outdoor adventurers. This trailer has much to offer, especially with the additional extra features.

Rear large draw-out rack
Side draw-out rack
Washing table nylon storage rollers and two elastic bungee cords
Lockable water tank filler cap
Stainless steel washing table mounting brackets
Zinc galvanised coupler ‘Sigma Autoreverse type’
Two pad-lockable jerry can holders
One heavy duty roof rack with table compartment able to carry a large tent
Two pad-lockable enclosures (equipment or tool box)
Two extending supporting back stays and one jockey wheel to provide leveling and stability when parked on uneven ground
15 inch 6 stud rims with 215 Trakgrip tires for rough terrain
One spare wheel
Epoxy coated in white, beige or green, manufactured from quality zinc galvanised sheet steel
4 ring holders to tighten luggage
Adjustable jockey wheel
Axle capacity 1800kg
2 Gabriel shock absorbers
12 blade 36-inch leaf springs
Lockable tailgate that serves as a table top
Multi-function LED lights
1 x pad-lockable toolbox/electrical box with caravan plug
Swing-out spare wheel attachment with maintenance free vesconite bushes
Large new nosecone with 4 tie-down rings able to house an 80-litre fridge, accessible from the front, with spring assisted flap for access to fridge controls

Optional Equipment

Tent with ladder for two to four adults (tent fitted if bought with trailer)
Gas stove kitchen unit with spice rack
Lid Netbag storage

Dimensions
A Height (over all) 1670 mm
B Height (side) 800 mm
C Length (body) 2100 mm
D Length (over all) 3800 mm
E Width (inside) 1100 mm
F Width (over all) 1780 mm
G Ground Clearance 330 mm
I Length (nose-cone) 670 mm
Technical Info
Tare Mass 500 kg
GVM 1530 kg
Pay Load 1030 kg
Brakes Run-in
Axle Length 1500 mm
Axle Capacity 1800 kg
Leaf Springs 12 Blade 36 inch
Wheels 215 x 15 inch
Doors
Door (rear – height) 560 mm
Door (rear – width) 1020 mm
Door (side – height) 540 mm
Door (side – width) 650 mm
