Voyager 14″ 7 ft with cycle rack
Voyager is a new series of leisure trailer that sports economy and maximim space utilisation.
The trailer sports a deeper body than standard trailers, allowing for storage of typical camping equipment inside. Access to the interior is very easy with a rear tailgate and a gas-assisted top lid.
Added stability when parked, comes from two extension legs, that neatly tuck away. It features superb space utilisation getting more into less. This trailer has the following:
Features
• A deep body of over 500 mm for those larger items
• Body constructed of zinc galvanised sheet steel
• A large nosecone for additional storage
• 14 inch wheels for rough terrain, plus spare wheel
• Two extension legs providing stability on uneven ground
• A robust cycle rack for carrying four bicycles
• A wide rear tailgate for access to the trailer interior
• A gas lift assisted flip-up trailer lid allowing for easy access to the trailer interior
• 6 inch adjustable jockey wheel
• 36 inch 6 blade leaf springs
• 8 ring holders for securing luggage inside
• Very sturdy coupler
• Strong construction using 30% more steel than standard trailers
• A long life 1250kg axle
• Numberplate twin light fitting
• Aluminium handles
• New multi-function LED light
• New numberplate holder
Nosecone Sizes
Link to NEW cycle rack 29 inch
| Dimensions | ||
| A | Height (over all) | 1255 mm |
|---|---|---|
| B | Height (side) | 640 mm |
| C | Length (body) | 2105 mm |
| D | Length (over all) | 3055 mm |
| E | Width (inside) | 1135 mm |
| F | Width (over all) | 1575 mm |
| G | Ground Clearance | 300 mm to bottom of axle |
| I | Length (nose-cone) | 650 mm |
| Technical Info | |
| Tare Mass | 280 kg |
| GVM | 750 kg |
| Pay Load | 470 kg |
| Axle Length | 1400 mm |
| Axle Capacity | 1250 kg |
| Leaf Springs | 8 Blade 36 inch |
| Wheels | 195 x 14 inch |
| Doors | |
| Door (rear – height) | 500 mm |
| Door (rear – width) | 620 mm (J) |
